Things Are Better Understandable When It Is Done/Experienced Practically The Department of EE takes immense care in providing the finest hands on experience with the help of well equipped laboratories. There are 12 labs, with all facilities aimed at providing better practical knowledge to the students.
Basic Electrical Engineering Lab
Network Theory Lab
Electrical Machines Lab-I
Power Electronics Lab
Electrical Power Transmission and Distribution Lab
Electrical Machines Lab-II
Control & Instrumentation Lab
Power System operation & Control lab
This lab is aimed at providing in depth knowledge on the Electrical Network and circuits. Network theory is the study of solving the problems of electric circuits or electric networks. Understand the use of circuit analysis theorems and methods. Predict the transient response of first and second order circuits.
Network theorem Kits
DC Motor Generator set
B-H Curve apparatus
1-Phase Energy meter
Megger
This lab is aimed at providing in depth knowledge on the Electrical Network and circuits. Network theory is the study of solving the problems of electric circuits or electric networks. Understand the use of circuit analysis theorems and methods. Predict the transient response of first and second order circuits.
Network theorem Kits
Series & Parallel Resonance R-L-C circuit
Low Pass & High Pass Filter
Band pass & Band Elimination Filter
Z & Y Parameter
ABCD & h-Parameter
AC & DC Transient
Spectrum analyser
The electrical machines laboratory is the one of the important laboratory of Electrical Engineering Department. The laboratory is equipped with various AC and DC electrical machines and transformers. This laboratory caters the need of UG and PG students to enable them to easily understand the basics and adapt to advanced experiments.
SQ. cage induction motor coupled with alternator with panel
DC shunt motor coupled with salient pole alternator capacity
DC shunt motor coupled with shunt generator capacity
DC shunt motor coupled with alternator-3 phase
DC motor with pony brake arrangement capacity
Salient pole type alternator
Transformers
DC Shunt motor
DC Series motor
DC Compound motor
DC Shunt generator
DC Series generator
DC Series compound generator
Single phase Squirrel cage induction motor
Three phase Squirrel cage induction motor
Single phase transformers
Three phase transformers
Slip ring Induction motor
Alternator
Synchronous motor
The lab aims at imparting practical knowledge of Power Electronics to the students at various levels i.e. B.Tech and M.Tech. It is accordingly well equipped with equipment and trainer kits to teach practical from fundamentals to high level concepts to the students, learn the characteristics of different types of power electronic devices, understand and analyze the operation of controlled rectifiers, choppers & inverters.
MOSFET/IGBT/SCR/DIAC/TRIAC
Characteristic kit
SCR Triggering Trainer
Single Phase cycloconverter
FWR and HWR modules
Resonant DC-DC converters modules
Series and parallel inverter
IGBT based chopper modules, voltage communication choppers
R,RC,UJT firing modes, SCR, TRIAC, MOSFET modules
Single phase and three phase PWM inverter modules
Single phase cyclo converters
Transmission & distribution plays a vital role in modern power system network, right from generation through transmission to distribution end. It is very important in any modern power system network. Switchgear helps run the electrical appliances in a streamlined manner and protects the equipment from overload Short-Circuit damage. Switchgear and Protection lab is used to make students familiar with the working of various switchgear equipment used for power system protection and performance of these equipments.
Combined Over Current & Earth Fault Relay
Reverse Power Relay
Differential Relay
Directional Relay
Distance Relay
Feeder Protection using Relay REM-615
Transmission & Distribution is a very crucial part of a power system. The main objective of power system operation and control is to maintain continuous supply of power with an acceptable quality, to all the consumers in the system. To understand the day to day operation of the power system and the control actions to be implemented on the system to meet the minute-to-minute variation of system load demand various Practicals are designed. Practicals covers all power system operation and control concepts with and without constraints like load flow analysis for IEEE bus system, Economic load dispatch with reserve capacity, Load frequency control with tie line control and flat frequency control, Contingency analysis with line outage and generator outage etc. to understand the variation of power system parameters under normal and abnormal conditions. Mi-Power and MATLAB software is used for simulation of these experiments.
Control Theory Laboratory takes care of teaching at the graduate level in basics of control and instrumentation. The advancement of science and technology is dependent upon a parallel progress in measurements techniques. To keep ourselves updated in modern developments and technologies a practical knowledge of control systems is essential. Our Control system lab has been catering the above mentioned service to the students.
MATLAB2010 and MATLAB2016 Software
Open Loop Control System
Closed Loop Contol System
Standard Test Signal generator kit
TYPE-0,1,2 Steady State analysis Adtron kit
Wheatstone bridge, Anderson bridge, Kelvin’s double bridge, scherings bridge, desauty bridge kits.
CRO’S regulated power supply
Strain gauge, pressure gauge kits
LVDT Kits
Energy meters to measure power etc.
Strain Gauge
P,PI,PID Controller
Switchgear protection plays a vital role in modern power system network, right from generation through transmission to distribution end. Switchgear protection is very important in any modern power system network. Switchgear helps run the electrical appliances in a streamlined manner and protects the equipment from overload Short-Circuit damage. Switchgear and Protection lab is used to make students familiar with the working of various switchgear equipment used for power system protection and performance of these equipments.
Combined Over Current & Earth Fault Relay
Reverse Power Relay
Differential Relay
Directional Relay
Distance Relay
Feeder Protection using Relay REM-615
Power system Operation and control is a very crucial part of a power system. The main objective of power system operation and control is to maintain continuous supply of power with an acceptable quality, to all the consumers in the system. To understand the day to day operation of the power system and the control actions to be implemented on the system to meet the minute-to-minute variation of system load demand various practicals are designed. Practicals covers all power system operation and control concepts with and without constraints like load flow analysis for IEEE bus system, Economic load dispatch with reserve capacity, Load frequency control with tie line control and flat frequency control, Contingency analysis with line outage and generator outage etc. to understand the variation of power system parameters under normal and abnormal conditions. Mi-Power and MATLAB software is used for simulation of these experiments.
